EV Charging Adaptors

DC1000V 150A 150KW CCS2 To CCS1 EV Charging Adaptor Car Charging Connectors EVSE Adaptor

DC1000V 150A 150KW CCS2 To CCS1 EV Charging Adaptor Car Charging Connectors EVSE Adaptor

Rated current: 150A
Rated voltage: 1000V DC
Operation Temp.:-30℃ ~ + 50℃
IP protection class: IP 44 ( working condition)
Product description: This DC1000V 150A 150KW CCS2 To CCS1 EV Charging Adaptor with a CCS2 Socket and a CCS1 Charging Cord. with help of it you can charge your CCS1 type Electric Car with a CCS2 EV Charging Station.
INQUIRY

DC1000V 150A 150KW CCS2 To CCS1 EV Charging Adaptor Car Charging Connectors EVSE Adaptor

Product Parameters

Standard	CCS Combo 2 to CCS Combo 1 Adapter
Current	150A
Operating Voltage	1000V DC
Color	White, black or customized
Warranty	12 months
IP Grade	IP 44
Operating Temperature	-30℃~+50℃

Electric Performance
Rated current : 150A
Operating voltage : 1000V DC
Insulation resistance : >2000MΩ (DC1000V)
Terminal temperature rise :<50K
Withstand voltage :3200V
Vibration resistance :Meet JDQ 53.3 requirements
Contact impedance:0.5MΩ Max

Mechanical properties
Mechanical life:no-load plug in/pull out>10000times
Insertion and extraction :70N<140n

Materials
Shell Materials :Thermoplastic(insulator inflammability UL 94V0)
Contact bush :Copper alloy, silver plating
Sealing gasket :rubber or silicon rubber

Environmental performance
Operating temperature:-30°C--+50
